PNY CS2241 500GB NVMe SSD Gen4x4 M.2 4700MB/s 1700MB/s R/W TBW 1.5M hrs MTBF 5yrs wty

PNY CS2241 500GB NVMe SSD Gen4x4 M.2 4700MB/s 1700MB/s R/W TBW 1.5M hrs MTBF 5yrs wty

PRODUCT SPECIFICATIONS

• NAND Components - 3D Flash Memory
• Interface - PCIe Gen4 x4
• Form Factor - M.2 2280

PERFORMANCE (MAX SEQUENTIAL READ/WRITE)

• 4700 MB/s (Read), 1,700 MB/s (Write)

POWER

• PCIe Power Management - PS0/PS1/PS2/PS3/PS4,APST, ASPM, L1.2

OPERATING/STORAGE TEMPERATURE

• Operating Temperature 0°C ~ 70°C
• Storage Temperature -40°C ~ 85°C
• Certifications BSMI, CE, FCC, KCC

RELIABILITY/SECURITY

• Mean Time Between Failures (MTBF) 1,500,000 Hours
• Error Correction Code LDPC (Low Density Parity
• Check) ECC Algorithm
• Product Health Monitoring Self-Monitoring, Analysis and
• Reporting Technology (S.M.A.R.T)
• Full End-to-End Data
• path protection Supported

COMPATIBILITY

• RAID (0/1) Supported
• NVMe NVMe 1.4

• Retail Dimensions (L x W x H) 123 x 85 x 4.3 mm
• Product Dimension (L x W x H) 22 x 80 x 4 mm (Max)
• Weight 6.6g

APPLICATIONS
• An excellent choice for a mainstream performance upgrade to Gen4 technology in an NVMe enabled desktop or laptop computer
• High performance SSD with up to 8 times the performance as compared to SATA based SSDs

FEATURES AND BENEFITS
• Sequential Read of up to 5,100 MB/s and Write of up to 4,200 MB/s
• Faster boot up, quicker application launch, and improved overall system performance
• Reliable storage
• Low power consumption, cool and quiet operation
• Backed by a 5 year limited warranty or TBW & live US tech support*
