Fox Racing - V1 Raid Helmet - Rust Brown

Fox Racing V1 Raid Helmet – Rust Brown

General Description

The Fox Racing V1 Raid Helmet delivers an excellent combination of modern protection, precise fit and dependable ventilation for motocross and off-road riders. Its lightweight injection-moulded polycarbonate and ABS shell is designed to help disperse impact energy, while the integrated Mips® system provides additional protection against rotational motion during certain angled impacts.

Seven intake vents and four exhaust vents promote consistent airflow during demanding rides. A removable and washable interior makes maintenance easy, while the distinctive Rust Brown Raid graphics provide a rugged, modern finish.

Meeting ECE 22.06 and DOT safety standards, the V1 Raid is a versatile choice for recreational riders, developing racers and experienced off-road enthusiasts.

Key Features

• Mips® protection system helps reduce rotational motion during certain impacts
• Lightweight injection-moulded polycarbonate and ABS shell
• Adjustable visor with breakaway side screws
• Seven intake vents and four exhaust vents for optimum airflow
• Four shell sizes and five EPS sizes for a more precise fit
• Removable and washable comfort liner and cheek pads
• Removable mouth vent cover
• Padded EVA chin bar for additional comfort
• Meets ECE 22.06 and DOT safety standards
• Rugged Rust Brown Raid graphics
• Suitable for motocross, dirt bike and off-road riding

Technical Specifications

• Brand: Fox Racing
• Model: V1 Raid
• Style Number: 40616
• Colour: Rust Brown
• Helmet Type: Adult full-face motocross helmet
• Shell Construction: Injection-moulded polycarbonate and ABS
• Impact Liner: EPS
• Protection Technology: Mips®
• Shell Configuration: 4 shell sizes
• EPS Configuration: 5 EPS sizes
• Ventilation: 7 intake vents and 4 exhaust vents
• Visor: Adjustable with breakaway side screws
• Interior: Removable and washable comfort liner and cheek pads
• Mouth Vent: Removable cover
• Chin Bar: Padded EVA construction
• Adult Size Range: XS–XXL
• Safety Certifications: ECE 22.06 and DOT
• Recommended Use: Motocross, dirt bike, ATV and recreational off-road riding

Additional Information

Mips® Protection

The Mips® system uses a low-friction layer inside the helmet. During certain angled impacts, this layer is designed to allow controlled movement between the rider’s head and the helmet, helping reduce potentially harmful rotational forces.

Lightweight Shell Construction

The injection-moulded polycarbonate and ABS shell is engineered to disperse energy during an impact while maintaining a comfortable weight. Multiple shell and EPS sizes help create a more proportionate appearance and precise fit across the adult size range.

Ventilation and Comfort

Seven intake vents direct fresh air into the helmet, while four exhaust vents help remove warm air. This airflow system supports rider comfort during hot weather, extended trail rides and physically demanding motocross sessions.

The comfort liner and cheek pads are removable and washable, helping keep the interior clean and fresh after exposure to sweat, dust and mud.

Adjustable Breakaway Visor

The adjustable visor can be repositioned to suit the rider’s preference and riding conditions. Breakaway side screws are designed to release the visor during certain impacts, helping reduce the forces transferred through the visor and helmet.

Size and Fit

Measure around the widest part of the head, approximately 2.5 cm above the eyebrows, and compare the result with the Fox Racing size guide.

The helmet should fit firmly and evenly without creating painful pressure points. Once fastened, it should not rotate or move excessively. If your measurement falls between two sizes, consult the official sizing guide before purchasing.

Care Instructions

• Remove the liner and cheek pads before washing
• Hand wash removable components using cold water and mild soap
• Allow all components to air dry completely
• Clean the outer shell with a soft, damp cloth
• Do not use petrol, solvents or abrasive cleaning products
• Do not place the helmet or its components in a washing machine or clothes dryer
• Avoid contact with aerosol sprays, insect repellent and sunscreen, as these may damage the finish
• Store in a cool, dry location away from direct sunlight and extreme heat

Safety Notice

Inspect the shell, visor, interior and fastening system before every ride. Replace the helmet following a significant impact, even if no visible damage is present. Never use a helmet that is cracked, heavily worn or incorrectly fitted.

Confirm that the helmet’s certification complies with the requirements applicable to your intended riding activity and Australian state or territory.
