Fox Racing - V1 Raid Helmet - Emerald

Fox Racing Youth V1 Raid Helmet – Emerald

General Description

The Fox Racing Youth V1 Raid Helmet combines advanced protection, reliable ventilation and a youth-specific fit for young motocross and off-road riders. Its lightweight injection-moulded polycarbonate and ABS shell is designed to disperse impact energy, while the integrated Mips® system provides additional protection against rotational motion during certain angled impacts.

Seven intake vents and four exhaust vents promote consistent airflow, helping young riders remain comfortable during training, racing and recreational riding. Finished in bold Emerald Raid graphics, this helmet delivers the distinctive Fox Racing look alongside practical safety and comfort features.

Key Features

• Youth-specific full-face motocross helmet
• Mips® system helps reduce rotational motion during certain impacts
• Lightweight injection-moulded polycarbonate and ABS shell
• One youth shell size and two EPS sizes for a precise fit
• Adjustable visor with breakaway side screws
• Seven intake vents and four exhaust vents
• Removable and washable comfort liner and cheek pads
• Removable mouth vent cover
• Padded EVA chin bar
• Meets ECE 22.06 and DOT safety standards
• Recommended for riders aged approximately 4–14 years
• Distinctive Emerald Fox Raid graphics

Technical Specifications

• Brand: Fox Racing
• Model: Youth V1 Raid
• Style Number: 40618
• Colour: Emerald
• Helmet Type: Youth full-face motocross helmet
• Shell Construction: Injection-moulded polycarbonate and ABS
• Impact Liner: EPS
• Protection Technology: Mips®
• Shell Configuration: 1 youth shell size
• EPS Configuration: 2 EPS sizes
• Ventilation: 7 intake vents and 4 exhaust vents
• Visor: Adjustable with breakaway side screws
• Interior: Removable and washable comfort liner and cheek pads
• Mouth Vent: Removable cover
• Chin Bar: Padded EVA construction
• Available Sizes: Youth Small, Youth Medium and Youth Large
• Approximate Weight: 1,080 ± 50 g
• Safety Certifications: ECE 22.06 and DOT
• Recommended Use: Motocross, dirt bike, ATV and recreational off-road riding

Youth Size Guide

Measurements and weights are approximate. Always measure the rider’s head before selecting a size.

Additional Information

Mips® Protection

The Mips® system incorporates a low-friction layer inside the helmet. During certain angled impacts, this layer allows controlled movement between the rider’s head and the helmet, helping reduce rotational forces that might otherwise be transferred to the brain.

Youth-Specific Fit

The Youth V1 uses a dedicated youth shell and two EPS sizes to provide a secure and proportionate fit. The helmet should sit firmly and evenly around the rider’s head without causing painful pressure points.

It should not rotate or move excessively when the chin strap is correctly fastened. If the rider’s measurement falls outside the youth sizing range, select a suitable adult helmet rather than forcing an incorrect youth size.

Ventilation and Comfort

Seven intake vents direct fresh air through the helmet, while four exhaust vents help release warm air. The removable comfort liner and cheek pads make it easier to maintain a clean and fresh interior after hot, dusty or muddy riding sessions.

Adjustable Breakaway Visor

The adjustable visor can be repositioned according to the rider’s needs. Breakaway side screws are designed to release the visor during certain impacts, helping reduce the forces transmitted through the visor and helmet.

Care Instructions

• Remove the liner and cheek pads before washing
• Hand wash removable components using cold water and mild soap
• Allow all components to air dry completely
• Clean the outer shell with a soft, damp cloth
• Do not use solvents, petrol or abrasive cleaning products
• Do not place the helmet or liner in a washing machine or clothes dryer
• Avoid contact with aerosol sprays, insect repellent and sunscreen, as these may damage the helmet’s finish
• Store in a cool, dry place away from direct sunlight and extreme heat

Safety Notice

An adult should confirm the helmet fits correctly and that the chin strap is securely fastened before every ride. Inspect the shell, visor, liner and fastening components regularly.

Replace the helmet after a significant impact, even when no external damage is visible. Confirm that its certification complies with the regulations applicable to the intended activity and Australian state or territory.
