Nami Klima - 67.2v 5A (XT30 Connector) - Replacement Charger

NAMI Klima – 67.2V 5A Replacement Charger – XT30 Connector

GENERAL DESCRIPTION

Recharge a compatible NAMI Klima electric scooter with this high-output replacement charger. Designed for selected 60V lithium-ion battery systems, it provides a regulated 67.2V DC output at up to 5A for faster charging than lower-current standard chargers.

The charger uses an XT30 output connector and features an LED status indicator for convenient charging monitoring. Integrated electrical protection helps guard against overvoltage, overcurrent, overheating and short circuits during normal operation.

KEY FEATURES

• Designed for selected NAMI Klima electric scooters

• Suitable for compatible 60V lithium-ion battery systems

• Regulated 67.2V DC charging output

• Maximum output current of 5A

• Maximum output power of approximately 336W

• XT30 output connector

• Faster charging than standard lower-amperage chargers

• Constant-current and constant-voltage charging

• LED indicator displays charging status

• Built-in overvoltage protection

• Overcurrent and short-circuit protection

• Thermal protection against excessive operating temperatures

• Integrated cooling system

• Suitable as a replacement or additional charger

TECHNICAL SPECIFICATIONS

Specification	Details
Product Type	Electric-scooter replacement charger
Compatible Scooter	Selected NAMI Klima models
Battery Compatibility	60V lithium-ion battery
Charger Output Voltage	67.2V DC
Maximum Output Current	5A
Maximum Output Power	Approximately 336W
Charging Method	CC/CV
Output Connector	XT30
Input Voltage	100–240V AC
Input Frequency	50/60Hz
Status Indicator	LED
Cooling	Integrated fan
Protection Features	Overvoltage, overcurrent, overheating and short-circuit protection
Intended Use	Indoor charging

PACKAGE INCLUDES

• 1 × 67.2V 5A replacement charger with XT30 connector

• 1 × AC mains power cable, where supplied

PLEASE NOTE

This is a replacement charger and should not be assumed to be a genuine NAMI component unless expressly stated by the supplier.

Before connecting the charger, confirm the battery voltage, XT30 connector gender and electrical polarity against the original charger and scooter wiring. Identical-looking XT30 connectors may use different polarity arrangements. An incorrect connector, voltage or polarity can cause serious battery damage, fire or personal injury.

Many standard NAMI Klima scooters use a reverse-polarity GX16 charging connection rather than a direct XT30 connector. An appropriate charging-port adaptor or internal harness may therefore be required. Do not modify the charger or scooter wiring unless the work is completed by a qualified technician.

Allow the scooter to cool before charging and use the charger only in a dry, ventilated location. Do not leave the scooter charging unattended or connected after charging is complete.
