Belkin Thunderbolt 3 Dock Core for Mac & Windows

Belkin Thunderbolt 3 Dock Core for Mac and Windows

Transform a compatible laptop into a complete workstation with the Belkin Thunderbolt 3 Dock Core. Through one integrated Thunderbolt 3 cable, the dock expands your computer with display outputs, USB connectivity, Gigabit Ethernet and a combined audio connection.

Supporting transfer speeds of up to 40Gbps, dual 4K displays and up to 60W USB-C Power Delivery pass-through, it is ideal for professional workstations, creative projects and hybrid working. Its compact design is suitable for permanent desk setups or travelling between workspaces.

General Specifications

• Brand: Belkin

• Model: Thunderbolt 3 Dock Core

• Model number: F4U110

• Product type: Thunderbolt docking station

• Compatible platforms: Mac and Windows

• Host connection: Integrated Thunderbolt 3 cable

• Maximum host data rate: Up to 40Gbps

• Charging pass-through: Up to 60W

• Colour: Black

Main Specifications

• Single-cable workstation connectivity

• Supports up to two 4K displays at 60Hz

• HDMI 2.0 and DisplayPort 1.4 video outputs

• Up to 60W USB-C Power Delivery pass-through

• Gigabit Ethernet for wired network access

• USB-A connections for peripherals and storage

• USB-C port for compatible devices and power input

• Combined 3.5 mm audio and microphone connection

• Compatible with Thunderbolt 3 Mac and Windows computers

Technical Specifications

Specification	Details
Host interface	Thunderbolt 3
Maximum host speed	Up to 40Gbps
Integrated host cable	Approximately 15 cm
HDMI	1 × HDMI 2.0
DisplayPort	1 × DisplayPort 1.4
USB-A	2 ports
USB-C	1 × USB-C Power Delivery port
Ethernet	1 × Gigabit Ethernet
Audio	1 × 3.5 mm TRRS audio and microphone port
Dual-display output	Up to 4K at 60Hz per display
Single-display capability	Up to 5K at 60Hz or 8K at 30Hz, subject to host support
Charging pass-through	Up to 60W USB-C PD
Power adaptor	Not included
Colour	Black

Computer Compatibility

Suitable for compatible:

• Thunderbolt 3 Windows laptops

• Thunderbolt 3 MacBook models

• Selected USB-C computers with supported DisplayPort and data functions

Available functions, display quantity and maximum resolution depend on the computer’s hardware, operating system and graphics capabilities. Some Apple silicon Mac models support only one external display through the dock.

Important Information

To provide pass-through charging, connect the laptop’s compatible USB-C Power Delivery adaptor to the dock. The computer must support Thunderbolt 3 or the required USB-C functions. A USB-C connection alone does not guarantee support for every display, charging or data feature.

What’s in the Box

• 1 × Belkin Thunderbolt 3 Dock Core

• 1 × Integrated Thunderbolt 3 host cable

• 1 × User documentation
